Gigabyte AORUS X870 STEALTH ICE Wi-Fi 7 ATX AM5 Motherboard

The GIGABYTE X870 AORUS STEALTH ICE is a high-performance ATX motherboard built on the AMD X870 chipset for the AM5 socket. Designed to support AMD Ryzen 7000, 8000, and 9000 series processors, this board focuses on clean aesthetics and simplified cable management. It features a robust 16+2+2 digital VRM phase solution to ensure stable power delivery for enthusiast-grade gaming and productivity riven systems.

Key Features

• Advanced Memory Support: Dual-channel DDR5 across four DIMM slots, supporting overclocked speeds up to 8200 MHz and AMD EXPO profiles.
• Next-Gen Storage: Four M.2 slots total, including PCIe 5.0 x4 support for ultra-fast NVMe performance alongside SATA III connectors.
• High-Speed Connectivity: Equipped with dual USB4 Type-C ports capable of 40Gbps and DisplayPort Alt mode, and integrated Wi-Fi 7 for the latest wireless standards.
• DIY Friendly Design: Features EZ-Latch Plus for quick-release PCIe and M.2 slots, M.2 EZ-Flex heat dissipation, and WIFI EZ-Plug for easy antenna installation.
• Premium Audio and Networking: Features the Realtek ALC1220-VB audio codec and a 5GbE LAN controller for low-latency wired networking.
• X3D Turbo Mode: Specialized BIOS optimization designed to enhance gaming performance for both X3D and non-X3D Ryzen processors.

Specifications

I/O & Connectivity

• Rear USB: 2 x USB4 Type-C, 1 x USB 3.2 Gen 2 Type-C, 2 x USB 3.2 Gen 2 Type-A, 4 x USB 3.2 Gen 1, and 4 x USB 2.0/1.1 ports.
• Internal USB: Header for USB 3.2 Gen 2x2 Type-C support.
• Display Outputs: 1 x HDMI 2.1 port (4096x2160@60 Hz) and 2 x USB4 ports (DisplayPort 1.4).
• Audio: 2 x Audio jacks and 1 x Optical S/PDIF Out.
• Expansion Slots: 1 x PCIe 5.0 x16 slot (actual speed dependent on CPU) and 1 x PCIe 4.0 x4 slot.
